4K Resolution 4.35mm Lens with Red NDVI Lens Mapping M12 for DJI Phantom Agriculture Modified


Specification:

NDVI (Normalized difference vegetation index) is the most common vegetation index, and is used to detect live, green, or photosynthetic capacity of plant canopies in multispectral remote sensing data. It is one of the most successful indices to quickly identify vegetated areas and their condition. This index can be used to analyze crops in all growth stages.


Model: LYX4.35-red

Aperture: f/2.8

Focal Length: 4.35mm

Optical Back Focal: 8.13 ± 0.1

Flange back Focal Length: 7.68 ± 0.1

Image Circle: Φ7.9 ( 1/2.3" )  Max Φ9 ( 1/1.8" )

Lens Structure: 13 Elements, All Glasses

Mount: M12*0.5

Barrel Material: All Metal

FOV: 1/2.3" (D*H*V): 86°*72°*56°

Distortion: -0.85%

CRA: 〈12.5°

Resolution:  more than 300 line pairs/mm

Operating Temperature: -20°C ~ +85°C

Installed Filter: RED NDVI

HSF & Safety: RoHS
